VEGABAR 86 pressure transmitter
$1,200.00
Submersible pressure transmitter with ceramic measuring cell
The VEGABAR 86 submersible pressure transmitter is designed for reliable hydrostatic level measurement in liquids, especially in harsh industrial environments.
- Ceramic measuring cell ensures high resistance to abrasion and corrosion
- Stable long-term operation under continuous immersion
- Suitable for wastewater, water treatment, and environmental monitoring
Not Recommended For:
• Dry gas pressure measurement
• Applications requiring non-submersible installation
Product catalog Hydrostatic
Product information VEGABAR 86, 87, VEGAWELL 52
Specification sheet VEGABAR 86
Operating instructions VEGABAR 86
Selection Notes
• Measurement Type: Designed for hydrostatic level and pressure measurement in liquids.
• Application Type: Suitable for water, wastewater, groundwater, and environmental monitoring.
• Measuring Cell: The ceramic measuring cell offers high resistance to corrosion, abrasion, and overload.
• Installation Method: Installed as a submersible probe, typically suspended in wells, tanks, or open water bodies.
• Output and Communication: Supports 4–20 mA, HART, or digital communication options.
Why Choose the VEGABAR 86
• Reliable Hydrostatic Measurement
The VEGABAR 86 measures liquid level via hydrostatic pressure. Therefore, it provides stable and accurate results in tanks, wells, and open water.
• Ceramic Measuring Cell for Durability
The ceramic cell offers excellent resistance to corrosion, abrasion, and pressure overload. As a result, it ensures long service life even in harsh environments.
• Submersible Design for Continuous Operation
The device is built for continuous immersion, making it ideal for long-term monitoring in water and wastewater applications.
• High Resistance to Environmental Conditions
It performs reliably in humid, submerged, and outdoor environments, including rivers, reservoirs, and groundwater systems.
• Low Maintenance and High Stability
Thanks to its robust design, the transmitter requires minimal maintenance while delivering consistent performance.
FAQ
Q: What applications is the VEGABAR 86 suitable for?
A: It is ideal for water and wastewater monitoring, including wells, tanks, rivers, and reservoirs.
Q: What is the advantage of a ceramic measuring cell?
A: A ceramic measuring cell provides strong resistance to corrosion, abrasion, and overload, ensuring long-term stability.
Q: Can it be fully submerged?
A: Yes. It is specifically designed for continuous submersion in liquids.
Q: Does it support digital communication?
A: Yes. It supports HART and other communication options for easy integration.
| Measuring range - Pressure | 0 … 25 bar [Bar – kPa – psi] |
|---|---|
| Process temperature | -20 … 100 °C [°C – °F] |
| Accuracy | 0.1 % |
| Materials, wetted parts | PVDF |
| Threaded connection | ≥ G1½, ≥ 1½ NPT |
| Flange connection | ≥ DN 40, ≥ 2" |
| Seal material | EPDM |
| Housing material | Plastic |
| Protection rating | IP66/IP68 (0,2 bar) |
| Output | Profibus PA |
| Ambient temperature | -40 … 80 °C |
| Scope | ATEX / Europe |
| Explosion protection | Intrinsic safety "i" |
| Foodstuffs/Pharma | 3A |
| Ship approval | ABS |
| Overfill protection | WHG |
| SIL qualification | SIL2 |
| Adjustment | PLICSCOM |
| Indication | Display/adjustment module PLICSCOM |
