VEGABAR 83

Pressure transmitter with metallic measuring cell

Application area

Universally applicable pressure transmitter. The ceramic measuring cell is resistant to temperature shocks. Can be combined with any other sensor of VEGABAR Series 80 for electronic differential pressure measurement.
The VEGABAR 82 pressure transmitter can be used universally for the measurement of gases, vapours and liquids. Substances such as sand can be handled easily thanks to the abrasion-resistant ceramic measuring cell. The VEGABAR 82 offers maximum reliability. The transmitter can be used in all industries. The simple connection of VEGABAR series 80 sensors as electronic differential pressure opens new possibilities for the measurement of differential pressures.

Your benefit

  • Low maintenance costs thanks to wear-free ceramic measuring cell
  • High plant availability through maximum overload and vacuum resistance of the ceramic measuring cell
  • Measurement down to the last drop through smallest measuring ranges with high accuracy

The pressure transmitter VEGABAR 83 is ideal for level and pressure measurement of liquids and viscous products with high process pressure. With its metallic measuring cell, the instrument delivers excellent measurement accuracy, even under a vacuum.

This pressure transmitter is the first choice for process pressure or level measurement in processes with high pressure, e.g. for

  • circuit pressure measurement in hydraulic pumps
  • pipeline pressure measurement
  • bitumen level measurerment in asphalt mixing plants
  • storage tank level measurement, e.g. for milk in dairies
Measuring range - Pressure

-1 … 1000 bar [Bar – kPa – psi]
Process temperature

-40 … 200 °C [°C – °F]
Accuracy

0.075 %
Materials, wetted parts

316L
Alloy C22 (2.4602)
316Ti (1.4571)
Alloy C4 (2.4610)
Threaded connection

≥ G½, ≥ ½ NPT
Flange connection

≥ DN15, ≥ ½"
Hygenic fittings

Slotted nut ≥ DN25 – DIN 11851
Varivent ≥ DN25
hygienic fitting with tension flange DN32
Hygienice flange connection ≥ DN50 DIN11864-2
SMS 1145 DN51
SMS DN38
Hygienic fittings ≥ DN33 – DIN11864-1-A
Hyg. collar clamp adapter DN40PN40 DIN11864-3-A
Hyg. clamp connection DIN11864-3-A; DN50 Rohr ø53
Swagelok VCR screwing
Varivent G125
Seal material

no media contact
Housing material

Plastic
Aluminium
Stainless steel (precision casting)
Stainless steel (electropolished)
Protection rating

IP66/IP67
IP66/IP68 (1 bar)
IP68 (0,2 bar)
IP66/IP68 (25 bar)
IP69
Output

Profibus PA
Foundation Fieldbus
4 … 20 mA
Two-wire: 4 … 20 mA/HART
Modbus
Secondary electronics for electronic differential pressure
Ambient temperature

-40 … 80 °C
Scope

ATEX / Europe
FM / USA
EAC (GOST) / Belarus
EAC (GOST) / Russia
IEC / worldwide
NEPSI / China
INMETRO / Brazil
CCOE / India
CSA / USA and Canada
IA
UKEX
Explosion protection

Intrinsic safety "i"
Flameproof enclosure "d"
Dust ignition protection "t"
Foodstuffs/Pharma

3A
EHEDG
FDA
EG1935/2004
Ship approval

ABS
BV
CCS
DNV
LR
RINA
Overfill protection

WHG
VLAREM II
SIL qualification

SIL2
Adjustment

PLICSCOM
PC, PACTware and DTM
HART-Communicator
Software (e. g. AMS™, PDM)
Indication

Display/adjustment module PLICSCOM
VEGADIS 81
VEGADIS 82
