VEGA BAR 81 VEGABAR 81 Pressure transmitter with chemical seal
$1,000.00
The VEGABAR 81 pressure transmitter with chemical seal provides reliable hydrostatic level measurement for aggressive and corrosive media. Designed for challenging process applications, this transmitter features a chemical seal that protects the measuring cell from harsh chemicals, viscous liquids, and clogging media. Ideal for chemical processing, petrochemical, and pharmaceutical industries, it ensures accurate level monitoring in tanks and vessels. With robust construction and various process connections, the VEGABAR 81 offers long-term stability and maintenance-free operation, making it perfect for demanding applications where standard sensors would fail.
Application area
Your benefit
- Simple adaptation thanks to various configuration options
- Reliable measurement with temperatures up to 400 °C
- Reliable measurement independent of foam generation or tank installations
| Measuring range - Pressure | -1 … 1000 bar [Bar – kPa – psi] |
|---|---|
| Process temperature | -90 … 400 °C [°C – °F] |
| Process pressure | -1 … 1000 bar [Bar – kPa – psi] |
| Accuracy | 0.2 % |
| Materials, wetted parts | Alloy C22 (2.4602) |
| Threaded connection | ≥ G½, ≥ ½ NPT |
| Flange connection | ≥ DN25, ≥ 1" |
| Hygenic fittings | Clamp ≥ 1" – DIN32676, ISO2852 |
| Seal material | no media contact |
| Housing material | Plastic |
| Protection rating | IP66/IP68 (0,2 bar) |
| Output | Profibus PA |
| Ambient temperature | -40 … 80 °C |
| Scope | ATEX / Europe |
| Explosion protection | Intrinsic safety "i" |
| Foodstuffs/Pharma | FDA |
| Ship approval | ABS |
| Overfill protection | WHG |
| SIL qualification | SIL2 |
| Adjustment | PLICSCOM |
| Indication | Display/adjustment module PLICSCOM |
