Level Measurement
VEGASON S61 Ultrasonic sensor for continuous level measurement for measuring ranges up to 5 m
$1,200.00
Measures liquids up to 5 m and bulk solids up to 2 m away
Operating instructions VEGASON S61
VEGASON S61
Ultrasonic sensor for continuous level measurement for measuring ranges up to 5 m
Application area
Output signal 4 … 20 mA, Ex approval and PLICSCOM optional.
The VEGASON S 61 is an ultrasonic sensor for continuous level measurement of liquids or bulk solids. Typical applications are the measurement of liquids in storage tanks or open basins. The sensor is also suitable for the detection of bulk solids in small vessels or open containers. The non-contact measuring principle is independent of product features and allows a setup without medium.
For this instrument, new radar sensors with connection housing VEGAPULS 11, 21 or 31, or radar sensors with fixed connected cable VEGAPULS C 11, C 21, C 22 or C 23 are available as alternative.
| Measuring range - Distance | 5 m [Meter – Foot] |
|---|---|
| Process temperature | -40 … 80 °C [°C – °F] |
| Process pressure | -0.2 … 2 bar [Bar – kPa – psi] |
| Accuracy | ± 4 mm |
| Materials, wetted parts | PVDF |
| Threaded connection | G1½ |
| Seal material | EPDM |
| Housing material | Plastic |
| Protection rating | IP66/IP67 |
| Output | 4 … 20 mA |
| Ambient temperature | -40 … 80 °C |
| Scope | ATEX / Europe |
| Explosion protection | Intrinsic safety "i" |
