VEGABAR 18 Pressure transmitter
Pressure transmitter

VEGABAR 18 Pressure transmitter

Original price was: $400.00.Current price is: $330.00.

Application area

4 … 20 mA, thread ½”

VEGABAR 18 is a universal pressure transmitter with 4 … 20 mA output and ceramic measuring cell for measurement of gases, vapours and liquids up to 100 °C. VEGABAR 18 is an economical solution for a variety of applications in all industrial sectors.

Your benefit

  • High plant availability through maximum overload and vacuum resistance of the ceramic measuring cell
  • Price-favourable version with small mounting dimensions
Category: Tags: , Brand:

VEGABAR 18 Pressure transmitter With ceramic measuring cell, basic version

VEGABAR 18 Device overview

The VEGABAR 18 pressure transmitter with ceramic measuring cell can be used universally for measurement of gases, vapours and liquids.
The device is an economical solution for a variety of applications in all industrial sectors.

Application area

4 … 20 mA, thread ½”
VEGABAR 18 is a universal pressure transmitter with 4 … 20 mA output and ceramic measuring cell for measurement of gases, vapours and liquids up to 100 °C. VEGABAR 18 is an economical solution for a variety of applications in all industrial sectors.

Your benefit

  • High plant availability through maximum overload and vacuum resistance of the ceramic measuring cell
  • Price-favourable version with small mounting dimensions
Measuring range - Pressure

0 … 25 bar
Process temperature

-40 … 212 °F
Accuracy

0,5 %
Materials, wetted parts

316L
Ceramic
Threaded connection

≥ G½, ≥ ½ NPT
Seal material

FKM
Protection rating

IP66/IP67
Output

4 … 20 mA
Ambient temperature

-40 … 158 °F
